Timber frame and panel houses

Insulation method – north wall

1. Inner surface: plasterboard / cladding board
2. Timber battens / insulation material
3. Air and vapour barrier
4. Load-bearing timber frame / insulation material
5. Wind barrier: wood fibre boards, insulated wind barrier boards or plasterboard
6. Joints sealed with tape to cover possible thermal bridges
7. Timber frame, 22-25 x 45-100 mm / ventilation gap
8. Cladding: cladding boards, decorative panels and similar
